ClaroTechnico 2008 at DD University Nadiad

Recently I was invited to present a guest lecture at the DD University (Nadiad) during their ClaroTechnico 2008 event. I presented a lecture on hacking and covered topics like types of hacking, history of hacking, anatomy of a hack, etc. Here are some photographs of the event.

System Information on Desktop

I had long forgotten the BGInfo utility from sysinternals (now Microsoft) which shows the system information on the desktop. What it does is allow you to pick up items like CPU, RAM, IP information, Hostname, Disk Space, etc. and show them on the desktop. Advantage? Saves time as you have to go through number of clicks before you can collect all the information. Here is a screenshot of how the software looks like:

Download from here

Once configured with the items that you want to show on your desktop, you need to add it to run auomatically on startup. No, the program does not run in the background but creates a bitmap file which you can use as a desktop.

Now that I've been reminded of this nice utility, I'm going to add this to all my servers running in the office. I would not recommend using this on live servers which are connected directly to the Internet i.e. servers which can be connected directly via Remote Desktop Protocol (RDP). Since the desktop from this software is visible even at the login box, anyone can connect to your server and pull out important information. Unless you have secured RDP to listen only from particular IP, or have setup access to servers after VPN, I strongly object the use of this software. Overall, I just love this utility and here is a snap of a desktop from one of my test servers in office.

Windows Updates Check on Nagios

I'm not much of a Linux guy but still love Nagios. Few days back I came across a script on Nagios Exchange (http://www.nagiosexchange.org/cgi-bin/page.cgi?g=Detailed%2F2639.html;d=1 ) which does a check for Windows updates and reports the results back to the Nagios server. The moment I saw it, I was very happy and I wanted to set this up. But the happiness did not last for long. Few hours later I found that it was not going to be easy to set this up and get it running. The problem is not the script - the problem is me. Always had been away from the Red Devil and Penguin since Windows always was my passion.

Searched a lot on the Internet and forums but I could not find a single site which would show how to implement the script in NsClient ++ and how to define the command and service in Nagios. Finally, I managed to crack it and now I would like to share this with everyone who may need some help on this.

Follow these steps to get this working:

[1] Download the script from Nagios Exchange and store it on your hard disk of your server which you need to check for updates. Note down the path to the wsf script for further reference.

[2] Edit your NSC.INI file (NsClient ++) and add this line to it:
check_updates=c:\windows\system32\cscript.exe //NoLogo //T:40 C:\Scripts\checkupdates.wsf $arg1$
The line above will check for the checkupdates.wsf script under the Scripts folder and run it using cscript. The $arg1$ will return the value back to Nagios.

[3] Next step is to add a command to your Nagios command.cfg file:
#'check_nrpe' command definition
define command {
command_name check_nrpe
command_line $USER1$/check_nrpe -H $HOSTADDRESS$ -p 5666 -c $ARG1$ -a $ARG2$
}

[4] Now it's time to define the service. Depending on the way you use templates, I'll leave it up to you to decide where to place it. Add the following lines:
# Monitor updates in windows machine
define service{
use generic-service
host_name Name Of Host - replace this with your Host Name
service_description Updates
check_command check_nrpe!check_updates!-l
}

Do a pre-flight check of Nagios. If no configuration errors are reported then you are good to go. Restart nagios for the new checks to work.

Securing IIS 6.0 Web Server on Windows 2003

Hacking a Web Server
With the advent of Windows 2003 and IIS 6.0 there was a sharp turn in the way hosting services were being provided on Windows platform few years back. Today, web servers running on Internet Information Services 6.0 (IIS 6.0) are highly popular worldwide – thanks to the .NET and AJAX revolution for designing web applications. Unfortunately, this also makes IIS web servers a popular target amongst hacking groups and almost every day we read about the new exploits being traced out and patched. That does not mean that Windows is not as secured as Linux. In fact, it’s good that we see so many patches being released for Windows platform as it clearly shows that the vulnerabilities have been identified and blocked.

Many server administrators have a hard time coping up with patch management on multiple servers thus making it easy for hackers to find a vulnerable web server on the Internet. One good way I have found to ensure servers are patched is to use Nagios to run an external script on a remote host, in turn alerting on the big screen which servers need patches and a reboot after the patch has been applied. In other words, it is not a difficult task for an intruder to gain access to a vulnerable server if the web server is not secured and then compromise it further to an extent that there is no option left for the administrator but to do a fresh OS install and restore from backups.

Many tools are available on the Internet which allows an experienced or a beginner hacker to identify an exploit and gain access to a web server. The most common of them are:

IPP (Internet Printing Protocol) - which makes use of the IPP buffer overflow. The hacking application sends out an actual string that overflows the stack and opens up a window to execute custom shell code. It connects the CMD.EXE file to a specified port on the attacker’s side and the hacker is provided with a command shell and system access.

UNICODE and CGI-Decode – where the hacker uses the browser on his or her computer to run malicious scripts on the targeted server. The script is executed using the IUSR_ account also called the “anonymous account” in IIS. Using this type of scripts a directory transversal attack can be performed to gain further access to the system.

Over these years, I’ve seen that most of the time, attacks on a IIS web server result due to poor server administration, lack of patch management, bad configuration of security, etc. It is not the OS or the application to blame but the basic configuration of the server is the main culprit. I’ve outlined below a checklist with an explanation to each item. These if followed correctly would help prevent lot of web attacks on an IIS web server.

Secure the Operating System
The first step is to secure the operating system which runs the web server. Ensure that the Windows 2003 Server is running the latest service pack which includes a number of key security enhancements.

Always use NTFS File System
NTFS file system provides granular control over user permissions and lets you give users only access to what they absolutely need on a file or inside a folder.

Remove Unwanted Applications and Services
The more applications and services that you run on a server, the larger the attack surface for a potential intruder. For example, if you do not need File and Printer sharing capabilities on your shared hosting platform, disable that service.

Use Least Privileged Accounts for Service
Always use the local system account for starting services. By default Windows Server 2003 has reduced the need for service accounts in many instances, but they are still necessary for some third-party applications. Use local system accounts in this case rather than using a domain account. Using a local system account means you are containing a breach to a single server.

Rename Administrator and Disable Guest
Ensure that the default account called Guest is disabled even though this is a less privileged account. Moreover, the Administrator account is the favorite targets for hackers and most of the malicious scripts out there use this to exploit and vulnerable server. Rename the administrator account to something else so that the scripts or programs that have a check for these accounts hard-coded fail.

Disable NetBIOS over TCP/IP and SMB
NetBIOS is a broadcast-based, non-routable and insecure protocol, and it scales poorly mostly because it was designed with a flat namespace. Web servers and Domain Name System (DNS) servers do not require NetBIOS and Server Message Block (SMB). This protocol should be disabled to reduce the threat of user enumeration.
To disable NetBIOS over TCP/IP, right click the network connection facing the Internet and select Properties. Open the Advanced TCP/IP settings and go to the WINS tab. The option for disabling NetBIOS TCP/IP should be visible now.
To disable SMB, simply uncheck the File and Print Sharing for Microsoft Networks and Client for Microsoft Networks. A word of caution though – if you are using network shares to store content skip this. Only perform this if you are sure that your Web Server is a stand-alone server.

Schedule Patch Management
Make a plan for patch management and stick to it. Subscribe to Microsoft Security Notification Service (http://www.microsoft.com/technet/security/bulletin/notify.asp) to stay updated on the latest release of patches and updates from Microsoft. Configure your server’s Automatic Update to notify you on availability of new patches if you would like to review them before installation.

Run MBSA Scan
This is one of the best way to identify security issues on your servers. Download the Microsoft Base Line Security tool and run it on the server. It will give you details of security issues with user accounts, permissions, missing patches and updates and much more.

That’s it to the basic of securing the operating system. There are more fixes which can be performed for further securing the server but they are beyond the scope of this article. Let’s now move on to securing the IIS web server.

IIS 6.0 when setup is secured by default. When we say this, it means that when a fresh installation of IIS is done, it prevents scripts from running on the web server unless specified. When IIS is first installed, it serves only HTML pages and all dynamic content is blocked by default. This means that the web server will not serve or parse dynamic pages like ASP, ASP.NET, etc. Since that is not what a web hosting server is meant to do, the default configuration is changed to allow these extensions. Listed below are some basic points that guide you to securing the web server further:

Latest Patches and Updates
Ensure that the latest patches, updates and service packs have been installed for .NET Framework. These patches and updates fix lot of issues which enhances the security of the web server.

Isolate Operating System
Do not run your web server from the default InetPub folder. If you have the option to partition your hard disks then use the C: drive for Operating System files and store all your client web sites on another partition. Relocate web root directories and virtual directories to a non-system partition to help protect against directory traversal attacks.

IISLockDown Tool
There are some benefits to this tool and there are some drawbacks, however, so use it cautiously. If your web server interacts with other servers, test the lockdown tool to make sure it is configured so that connectivity to backend services is not lost.

Permissions for Web Content
Ensure that Script Source Access is never enabled under a web site’s property. If this option is enabled, users can access source files. If Read is selected, source can be read; if Write is selected, source can be written to. To ensure that it is disabled, open IIS, right click the Websites folder and select Properties. Clear the check box if it is enabled and propagate it to all child websites.

Enable Only Required Web Server Extensions
IIS 6.0 by default does not allow any dynamic content to be parsed. To allow a dynamic page to be executed, you need to enable the relevant extension from the Web Service Extensions property page. Always ensure that “All Unknown CGI Extensions” and “All Unknown ISAPI Extensions” are disabled all the time. If WebDAV and Internet Data Connector are not required, disable that too.

Disable Parent Paths
This is the worst of all and thanks to Microsoft, it is disabled in IIS 6.0 by default. The Parent Paths option permits programmers to use ".." in calls to functions by allowing paths that are relative to the current directory using the ..\notation. Setting this property to True may constitute a security risk because an include path can access critical or confidential files outside the root directory of the application. Since most of the programmers and third-party readymade applications use this notation, I leave it up to you to decide if this needs to be enabled or disabled. The workaround to Parent Paths is to use the Server.MapPath option in your dynamic scripts.

Disable Default Web Site
If not required, stop the Default Web Site which is created when IIS 6.0 is installed or change the property of Default Web Site to run on a specific IP address along with a Host Header. Never keep it running on All Unassigned as most of the ready-made hacking packages identify a vulnerable web server from IP address rather than a domain name. If your Default Web Site is running on All Unassigned, it means that it can serve content over an IP address in the URL rather than the domain name.

Use Application Isolation
I like this feature in IIS 6.0 which allows you to isolate applications in application pools. By creating new application pools and assigning web sites and applications to them, you can make your server more efficient and reliable as it ensures that other applications or sites do not get affected due to a faulty application running under that pool.

Summary
All of the aforementioned IIS tips and tools are natively available in Windows. Don't forget to try just one at a time before you test your Web accessibility. It could be disastrous if all of these were implemented at the same time making you wonder what is causing a problem in case you start having issues.

Final tip: Go to your Web server and Run “netstat –an” (without quotes) at the command line. Observe how many different IP addresses are trying to gain connectivity to your machine, mostly via port 80. If you see that you have IP addresses established at a number of higher ports, then you've already got a bit of investigating to do.

Nagios and MSSQL 2005

Recently some of the hosts that I monitor and provide server administration support upgraded their MSSQL 2000 to MSSQL 2005. The problem started when we tried to add MSSQL 2005 database service to monitoring. Nagios would simply not check "MSSQL$SQLEXPRESS" and return a Unknown state. Obviously the $ in the middle of the service name was causing the issue. Found out later that we need to use either two $$ or quote the dollar sign so that it shows MSSQL$"$"SQLEXPRESS.

SharePoint Services 3.0 Installation

Since yesterday I've been trying to setup SharePoint Services 3.0 on a server which is running MS Exchange. Everytime when I start the installation, the installer reports back that the installation has been completed successfully and now I need to run the configuration wizard in order to finish the installation. I ran the wizard and it crashed at stage 2 where it tries to create a Configuration Database and reported an error stating: Failed to create the configuration database.

I opened the log file and got more details about the error:
An exception of type System.Data.SqlClient.SqlException was thrown. Additional exception information: Could not find stored procedure 'dbo.proc_getObjectsByClass'.System.Data.SqlClient.SqlException: Could not find stored procedure 'dbo.proc_getObjectsByClass'.

I also found the following error in Event Viewer under the Event ID 5586:
Unknown SQL Exception 2812 occured. Additional error information from SQL Server is included below.Could not find stored procedure 'dbo.proc_getObjectsByClass'.

...which was followed by Event ID 104:
Failed to create the configuration database.
An exception of type System.Data.SqlClient.SqlException was thrown. Additional exception information: Could not find stored procedure 'dbo.proc_getObjectsByClass'.
System.Data.SqlClient.SqlException: Could not find stored procedure 'dbo.proc_getObjectsByClass'.
at System.Data.SqlClient.SqlConnection.OnError(SqlException exception, Boolean breakConnection)
at System.Data.SqlClient.SqlInternalConnection.OnError(SqlException exception, Boolean breakConnection)

... and Event ID 100:
Configuration of SharePoint Products and Technologies failed. Configuration must be performed in order for this product to operate properly. To diagnose the problem, review the extended error information located at C:\Program Files\Common Files\Microsoft Shared\Web Server Extensions\12\LOGS\PSCDiagnostics_4_12_2008_14_11_5_734_1835669046.log, fix the problem, and run this configuration wizard again.

This problem had me for good and after numerous repairs, removals and retries, I called it a day. The next day I started searching for some resources on the Internet for this error and came across the following KB article: KB934790

Yes, I did have WSUS installed on this server and that was the cause. The problem had been nailed down. I got the hotfix, installed it and re-installed Sharepoint Services 3.0. This time it was a piece of cake.

VMWARE Nightmare

I had installed VMWARE on one of my Windows 2003 (SP2) server to run an image file of Linux. In order to upgrade the VMWARE software to it's latest version, I downloaded the new setup and ran it. It prompted me saying that the old version needs to be removed first and then the new one can be installed. Fortunately, it also told me that the Virtual Machines already configured will not be disturbed. That certainly brought a smile on my face, but not for long.

The uninstall process started but it seemed to keep crapping out. It would go so far (almost to the finish) and then just... sit there. Well, I almost sat there staring at the screen for a good 30-45 minutes, had 3-4 cups of coffee. Now this was torture.

I decided to kill the process and opened Task Manager. I could see 3 processes of msiexec.exe running along with the VMWARE-Server-Installer process. Surprised to see 3 process of msiexec.exe running, I picked a random one and killed it. To my surprise; the installtion proceeded and prompted me to choose if I wanted to keep the license key in the registry.

Hope this accidental discovery would help someone in the future.
